    Depth Road 120mm Milling Machine XM353 Road Construction Machinery

    Ask Lasest Price
    Model Number : XM353
    Certification : CE/ISO9001
    Price : Negotiable
    Payment Terms : T/T, L/C
    Supply Ability : 500 units/month
    Delivery Time : 10-15 days
    • Product Details
    • Company Profile

    Depth Road 120mm Milling Machine XM353 Road Construction Machinery

    0.35m Milling Width 120mm Deep Road Milling Machine XM353 with Detuz Engine

    XM353 is a municipal maintenance type milling machine, which is mainly used in milling operation for city streets and country roads, can also be used on small scale of pavement maintenance pavement marking, milling around the manhole cover, pit slot digging, etc.; Besides, it can be used as auxiliary equipment of large milling machine, to meet the requirement of edge milling planing.

    * Walking system: low speed three wheel walking, driven by full hydraulic system, which resolves the low gradeability and slipping phenomenon and cost reduction.
    * Suspension system: rear wheel is independent suspension-type supporting wheel. The right rear wheel can swing back inward, easy to mill the edge.
    * Milling system: adopt hydraulic mechanical transmission mode,stable and powerful; lmport tool bit, ensure the service life of the cutting tools.
    * Milling depth control: right and left rear legs allow lifting adjustment and wedge-shape milling; Depth indicator is installed on the rear leg, to show the milling depth. This device has optional automatic leveling system.
    * Steering system: full hydraulic steering, convenient and flexible manipulation.
    * Sprinkler system: fan shaped nozzles spray the water to the tool bits for cooling, at the same time also reduce the dust diffusion. The large capacity water tank can make the machine continuous work for longer hours. Electric pumps, high pressure spraying, sprinkler nozzles are easy to disassembly and clean.
    * Brake: two systems of service braking and parking braking.
    * Lighting system: this machine is equipped with night work head lamp, convenient for operation at night.

    Specification

    Item
    Unit
    XM353
    Milling width
    mm
    350
    Maximum milling depth
    mm
    120
    Tool nose distance
    mm
    12
    Number of tools
    36/48
    Rotor diameter with tool
    580
    engine model
    BF4M2012-10T3R
    Rated speed
    rpm
    2200
    Rated power
    kw
    72
    Emission Standards
    Euro III
    Fuel tank
    L
    110
    Hydraulic oil tank
    L
    70
    Water tank
    L
    260
    Working speed
    m/min
    0-40
    Walking speed
    km/h
    0-5.6
    Theoretical climbing ability
    %
    50
    Total weight
    kg
    4800
    Minimum milling radius
    mm
    130
    Ground clearance
    mm
    120
